40W/50W track light spotlight cob

Full Product Code:PS-TL-40W/50W-X16B90
  • General Information
  • Feature
  • Installation
  • Download

Description

Powerstar is commercial led lighting factory, specialized in led track lighting system, we pay attention to research the high end led track spotlight for our customers. Our track led light use famous brand driver like lifud /trodinic/philip/Osram, we can provide 5 and 7 years warranty. And we passed the CE/RHOS/TUV/SAA/CB certification.


For this 40W led spotlight track with external driver, the heat dissipation is very good, and we use Citizen V6/Luminus COB led chip, SDCM<3, the CCT is below BBL, the color of light is very comfortable, customers can feel very relax and comfort when shopping.



General Information

Power 40W/50W
Housing materialDie-Casting Aluminum
Housing ColorBlack(9011)/White(9016)
Housing Size90x200mm
Light Source BrandCitizen/Cree/Luminus COB
CCT2700/3000/3500/4000/5000/5700K
Driver BrandTridonic/Osram/Philips/Boke
Optics typeReflector
Beam Angle15/24/38/60° Reflector
UGR19
Warranty5years
Track Adapter 2/3/4 wires
IP ClasssIP20
Qty/Cartons12Pcs/CTN GW18Kg
Carton Size51*42*27cm


Lighting Feature

Power  CCTCRISDCMLuminous Flux
40W/50W3000KCRI>80<3121lm/w
CRI>90<3104lm/w
CRI>97<393lm/w
4000KCRI>80<3124lm/w
CRI>90<3105lm/w
CRI>97<395lm/w


Operating and Electrical

Power 40W/50W
Voltage220-240V/50-60Hz
PF>0.95
THD<15
Flicker

Flicker Free

CertificationTUV/SAA/CE/CB/ENEC/RoHS
DimmableTriac



40/50W LED Track Light Features

1.40/50W reach 5500Lm output light efficiency.

2. 15°/24°/38°/60° lighting beam angle for options.

3.External driver design, fast heat dissipation.

4.Citizen/Luminus/Cree/Bridgelux brand chip.

5.5 years warranty.

40W/50W track light  spotlight cob


Create healthy and comfortable quality lighting.

Lighting quality refers to whether the lighting source meets the visual function, visual comfort, safety and visual aesthetics of lighting indicators. Lighting quality is related to the comfort and health of our living environment. The correct application of good lighting quality indicators, will bring a new feeling to your lighting space, especially in the era of LED lighting, lighting quality performance is extremely important, the use of lighting quality indicators to buy LED light source products, will bring twice the result with half the effort lighting effect. Our track lights use the brand Citizen, luminusLED, UGR<19, SDCM<3, the light is very soft, comfortable, no light spot.

40W/50W track light  spotlight cob


It supports rotation of 90° in vertical direction and 355° in horizontal direction.

Malls with shelves, stacks, side yards, center islands, and checkout counters ...... are typical lighting spaces that combine different product parameters based on accent and base lighting. Commodity visit will move position according to different display design, our track light can that rotate 90° in the vertical direction and 355° in the horizontal direction, so that the light can be freely oriented in any direction, well meet the mall or mobile goods lighting needs.





LED track light application:

The track light system breaks through most of the standard alternative light source forms on the market, the power is limited, the total luminous flux is not enough, the color rendering is not good, the lighting quality can not be guaranteed and other problems, 45W power luminous efficiency can reach 110lm/ W, luminous flux is nearly 5000lm, brightness fully meet the needs of most commercial lighting, light color consistency is good,  Color tolerance is less than 3, the same batch of goods do not have to worry about color difference, the production process is completely in accordance with the ISO9001 standard test, do not have to worry about quality problems, high light efficiency, good color rendering, low brightness, long life, used in shopping malls, supermarkets, 4S shops, fashion shops and other commercial lighting places.

40W/50W track light  spotlight cob
